Type 2 Socket to Type 1/J1772 Vehicle EV Charging Cable
Effortlessly charge your Type 1 electric or plug-in hybrid vehicle from a Type 2 charging station with our Type 2 to J1772 heavy-duty EV charging cable. This versatile solution ensures seamless compatibility and hassle-free charging, whether you're at home, at work, or on the go.
Compatibility:
- Car Charger Side: Type 1/J1772
- Charger Side: Type 2
Features:
- Versatile Compatibility: Allows Type 1 vehicles to charge from Type 2 sockets, eliminating the need for separate chargers.
- Robust Construction: Built to withstand heavy-duty use with a durable thermoplastic shell and copper alloy, silver-plated pins.
- Reliable Performance: Rated for 32A current, ensuring efficient and fast charging every time.
- Weatherproof Design: With an IP54 waterproof rating, it withstands outdoor elements for reliable performance in any environment.
- Safety Certified: CE, FCC, and ROHS certified for peace of mind, guaranteeing safety and quality standards are met.
Specifications:
| Item | Type2 To J1772 |
| Rated Operating Current | 32A |
| Operation Voltage | 250V(AC) |
| Insulation Resistance | >1000MΩ(DC500V) |
| Withstand Voltage | 2000V |
| Pin Material | Copper Alloy, Silver Plating |
| Shell Material | Thermoplastic, Flame Retardant Grade UL94 V-0 |
| Operating Temperature | No-Load Plug In / Pull Out >10000 Times |
| Contact Resistance | 0.5mΩ Max |
| Terminal Temperature Rise | <50K |
| Operating Temperature | -30℃⁓+50℃ |
| Impact insertion Force | >300N |
| Waterproof Degree | IP54 |
| Cable Length | 5Meter |
| Cable Protection | Reliability of materials, antiflaming, pressure-resistant, abrasion resistance impact resistance, and high oil |
| Certification | CE FCC ROHS |
Select Rated Current
Select Cable Length
Select Color
From $382.20
Original: $1,274.00
-70%Type 2 Socket to Type 1/J1772 Vehicle EV Charging Cable—
$1,274.00
$382.20
Description
Effortlessly charge your Type 1 electric or plug-in hybrid vehicle from a Type 2 charging station with our Type 2 to J1772 heavy-duty EV charging cable. This versatile solution ensures seamless compatibility and hassle-free charging, whether you're at home, at work, or on the go.
Compatibility:
- Car Charger Side: Type 1/J1772
- Charger Side: Type 2
Features:
- Versatile Compatibility: Allows Type 1 vehicles to charge from Type 2 sockets, eliminating the need for separate chargers.
- Robust Construction: Built to withstand heavy-duty use with a durable thermoplastic shell and copper alloy, silver-plated pins.
- Reliable Performance: Rated for 32A current, ensuring efficient and fast charging every time.
- Weatherproof Design: With an IP54 waterproof rating, it withstands outdoor elements for reliable performance in any environment.
- Safety Certified: CE, FCC, and ROHS certified for peace of mind, guaranteeing safety and quality standards are met.
Specifications:
| Item | Type2 To J1772 |
| Rated Operating Current | 32A |
| Operation Voltage | 250V(AC) |
| Insulation Resistance | >1000MΩ(DC500V) |
| Withstand Voltage | 2000V |
| Pin Material | Copper Alloy, Silver Plating |
| Shell Material | Thermoplastic, Flame Retardant Grade UL94 V-0 |
| Operating Temperature | No-Load Plug In / Pull Out >10000 Times |
| Contact Resistance | 0.5mΩ Max |
| Terminal Temperature Rise | <50K |
| Operating Temperature | -30℃⁓+50℃ |
| Impact insertion Force | >300N |
| Waterproof Degree | IP54 |
| Cable Length | 5Meter |
| Cable Protection | Reliability of materials, antiflaming, pressure-resistant, abrasion resistance impact resistance, and high oil |
| Certification | CE FCC ROHS |
